Driver's Door Lock Actuator Seized & Driver's Seat Motor Stopped Working

Y

Youdey

Member
 Cardiff
My 2003 Z4 Driver's Door Lock Actuator seems to have seized, as I can't open the door from the outside or the inside of the car. I have had issues in the past opening the door using the key fob, as the driver's side didn't want to lock & unlock, so I have had to use the physical key. The passenger door & petrol cap all lock & unlock fine, so I don't think it would be an electrical issue, but I am not certain. I have tried the central locking button inside the car, which locks & unlocks the rest of the car fine but not the driver's door. I have taken the door card off & have accessed where the cables attach to the actuator to make sure that they have not stretched. They are fine & pull the levers enough to open the door. The white plastic clip that goes up & down to show if the door is locked is stuck in the down position, which means it is locked & I haven't been able to get it to unlock at all. I am currently stuck as to what to do & believe my only option left is to try drilling into the mechanism. If anyone has any experience or advice about this, then please let me know.

Along with the Driver's Door Lock Actuator being seized, the Driver's Seat Motor also stopped working. I have checked the fuse & unfortunately it wasn't that. I am a little stuck on where to start with that, as I currently can't open the door to have a proper look at it.

Last edited:
I’m away on holiday with limited access to check stuff, but somewhere in the E85 How To section I have put a detailed description of how to get the door open. It will mean you need a new actuator but it sounds like yours has died anyway and the likes of @Umfaan should be able to supply a spare.

enuff_zed said:
I’m away on holiday with limited access to check stuff, but somewhere in the E85 How To section I have put a detailed description of how to get the door open. It will mean you need a new actuator but it sounds like yours has died anyway and the likes of @Umfaan should be able to supply a spare.
Click to expand...
Thanks, I'll try to find it. I had actually got a replacement as I knew it needed doing, but I just hadn't gotten around to replacing it.

enuff_zed

Thread 'Removing a door lock that will not open'

I have experienced the problem that I’ve heard a lot about in the past and dreaded happening to me.
Door closed and locked, press the key fob, or turn the key in the lock and the knob pops up but the door remains stubbornly shut. Unable to be opened from either the inside or the outside.
This is caused by an internal failure within the lock assembly and you are pretty much stuffed as you cannot remove the lock because two of the mounting screws are on the rear edge of the door.
If you are really lucky it may just be down to a build up of grime inside and a liberal soak with WD40 or similar...
