Z4 E89 2011 roof issue

E

Esso kamal

New member
I have got these fault codes
A689 Hall Sensor, Roof Pack Erected
A693 Microswitch, Roof Pack Stowed
Roof isn’t working in addition to windows are down and won’t go up

And......welcome to the forum.
Great introduction, well done! :thumbsup:

You can search directly in Google: site:www.z4-forum.com RobbieZ4 roof stuck

Sounds like another broken wire.
As roof moves the wires separate at the break and all comes to a stop. Until limit switch is triggered windows won't move up as system doesn't know status of roof, i.e closed.
Biggest problem now is access to boot to dump pressure to lift top roof panel over to gain access to wires.
There is a way to bridge the fuse box to unlock boot. I did my own boot mod for this eventuality, served me well.
I have had this 3 times now, just waiting for left wires to fail. I should just replace them now.
Just being lazy.

Search the forum covered many times.

Not sure if you are a DIY person or you prefer to take it to a dealer or specialist. If the latter, and you are in the south east region, then I have used Cayman autos in Redhill for mine when it failed in October.

flybobbie said:
Sounds like another broken wire.
As roof moves the wires separate at the break and all comes to a stop. Until limit switch is triggered windows won't move up as system doesn't know status of roof, i.e closed.
Biggest problem now is access to boot to dump pressure to lift top roof panel over to gain access to wires.
There is a way to bridge the fuse box to unlock boot. I did my own boot mod for this eventuality, served me well.
I have had this 3 times now, just waiting for left wires to fail. I should just replace them now.
Just being lazy.

Search the forum covered many times.
Click to expand...
pray tell of this boot mod you did please

I suspect you’re wasting your time..

The OP hasn’t been back since the day he posted it..

Joined:25 Nov 2024, 16:00Last active:25 Nov 2024, 22:59Total posts:1 | Search user’s posts
(0.00% of all posts / 0.33 posts per day)

peter2704 said:
flybobbie said:
Sounds like another broken wire.
As roof moves the wires separate at the break and all comes to a stop. Until limit switch is triggered windows won't move up as system doesn't know status of roof, i.e closed.
Biggest problem now is access to boot to dump pressure to lift top roof panel over to gain access to wires.
There is a way to bridge the fuse box to unlock boot. I did my own boot mod for this eventuality, served me well.
I have had this 3 times now, just waiting for left wires to fail. I should just replace them now.
Just being lazy.

Search the forum covered many times.
Click to expand...
pray tell of this boot mod you did please
Click to expand...
https://z4-forum.com/forum/viewtopic.php?p=1967743&hilit=boot+mod#p1967743

Can leave the wire loose and apply 12 volts or wire to a switch.
My car was missing the boot release switch so i modified such switch to apply 12 volts to wire.
So i can open boot in any roof position to access boot and pump.

B21 said:
I suspect you’re wasting your time..

The OP hasn’t been back since the day he posted it..
Joined:25 Nov 2024, 16:00Last active:25 Nov 2024, 22:59Total posts:1
Click to expand...
Another "mayfly"!
Same here in the German forum. :fuelfire:

RobbiZ4 said:
B21 said:
I suspect you’re wasting your time..

The OP hasn’t been back since the day he posted it..
Joined:25 Nov 2024, 16:00Last active:25 Nov 2024, 22:59Total posts:1
Click to expand...
Another "mayfly"!
Same here in the German forum. :fuelfire: :thumbsup:
Click to expand...
:rofl:
